Doosan DX 300
Nettó ár
Nyomtatás
INFÓ
Termékcsalád
Lánctalpas kotrók
Márka / modell
Doosan DX 300
Gyártási év
2024
Üzemóra
600 h
Ország
Kína
Általános besorolás
1
2
3
4
5
Mascus ID
830BAC40
ÁR
Pénznem kijelölése
TERMÉKLEÍRÁS
Raktári száma
1
Üzemmód
Dízel
Szériaszám
1
Előző tulajdonosok száma
1
Utolsó szemle
2025-07-07
Undercarriage condition
Good Condition
Motor
Original
Össztömeg
30 215 kg
Motorteljesítmény
159 kW (216 lóerő)
Motor gyártója
Original
Regisztrációs szám
1
Károsanyag kibocsátási osztály
EURO V
Kanál
1,60 m3
nyomtáv
600 mm
A kiegészítő hidraulika teljesítménye
248 l/perc
Csúcssebesség
5,70 km/h
Szállítási méretek (HxSzxM)
10615 x 3199 x 3515 mm
Eredeti szín
Original
Kanálszár hossza
3 100 mm
Garancia
1 Year
Gyártó ország
Dél-Korea
Szállítási feltételek
FCA, FOB, CIF, EXW
Tanúsítványok
EPA, CE
Mellékletek
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Tartozékok
alapgém zuhanásgátló szelep
kanálgém zuhanásgátló szelep
Twig wire box
Klíma
Kiegészítő hidraulika
motor előszűrő
rostkanál
forgó jeladó
dízel fűtőkészülék
joystick vezérlés
mélyásó kanál
kábelezett kanál
rakodó kanál
trapéz kanál
FOPS rácsos fülke
Egyéb információ
Parameter configuration of Doosan DX300LC-9C excavator
Specification
Power Traditional Power
Joint venture/import by manufacturers
Bucket backhoe
Tonnage (tons)30
The overall working weight of the machine (kg) is 30,215
Bucket capacity (m³) : 1.45/1.6
Boom length (mm) : 6245
The length of the boom (mm) is 3100
Performance
Rotational speed (rpm) : 9.4
Rotary torque (Nm)11760
Walking speed (km/h) 5.7/3.2
The ground pressure (Kpa) is 0.57 kg/cm ²
Bucket digging force (kN) : 183.3
The digging force of the bucket arm (kN) is 128.4
Power system
Engine model: DL08
Rated power (kw/rpm) 159/1,900
Number of cylinders (6
Cylinder diameter × stroke (mm)108 *309
Hydraulic system
The main pump type is a variable piston pump
The maximum flow rate of the main pump (l/min) is 2*248
Oil capacity
Fuel tank (L)500
Hydraulic oil tank (L)280
Main body size
Total transportation length (mm) : 10,615
The total transportation width (mm) is 3199
The total transportation height (mm) is 3,515
Total track length (mm) : 4,940
Track plate width (mm) : 600
Total width of the tracks (mm) : 3,200
Minimum ground clearance (mm) : 506
The ground clearance of the counterweight (mm) is 1,150
Rear end turning radius (mm) : 3,188
Number of idler wheels (single side) (units)9
Number of idler wheels (single side) (units)2
Number of track plates (single side) (pieces)48
Scope of work
Maximum excavation radius (mm) : 10702
The maximum excavation radius of the shutdown face (mm) is 10506
Maximum excavation depth (mm) : 7275
Maximum excavation height (mm) : 10315
Maximum unloading height (mm) : 7303
Maximum vertical excavation depth (mm) : 4907
Maximum effective excavation depth (mm) : 6,455
