Sany SY 135 C
Nettó ár
Nyomtatás
INFÓ
Termékcsalád
Lánctalpas kotrók
Márka / modell
Sany SY 135 C
Gyártási év
2024
Üzemóra
600 h
Ország
Kína
Általános besorolás
1
2
3
4
5
Mascus ID
69858500
ÁR
Pénznem kijelölése
TERMÉKLEÍRÁS
Raktári száma
1
Üzemmód
Dízel
Szériaszám
1
Előző tulajdonosok száma
1
Utolsó szemle
2025-07-01
Undercarriage condition
Good Condition
Motor
Original
Össztömeg
13 500 kg
Motorteljesítmény
73 kW (99,3 lóerő)
Motor gyártója
Original
Regisztrációs szám
1
Károsanyag kibocsátási osztály
EURO V
Kanál
0,60 m3
nyomtáv
500 mm
Csúcssebesség
5,50 km/h
Szállítási méretek (HxSzxM)
7700 x 2550 x 2815 mm
Eredeti szín
Original
Garancia
1 Year
Gyártó ország
Kína
Szállítási feltételek
FCA, FOB, CIF, EXW
Tanúsítványok
EPA, CE
Mellékletek
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Tartozékok
Twig wire box
Klíma
Kiegészítő hidraulika
motor előszűrő
rostkanál
Motorfűtő
akkumulátor kapcsoló
forgó jeladó
dízel fűtőkészülék
joystick vezérlés
mélyásó kanál
kábelezett kanál
trapéz kanál
Egyéb információ
Parameter configuration of Sany SY135C excavator
Specification
Power Traditional Power
Domestic manufacturer
Bucket backhoe
Tonnage (tons)13
The working weight of the entire machine (kg) is 13,500
Bucket capacity (m³)0.22-0.7 (0.6)
Performance
Rotational speed (rpm)12
Walking speed (km/h)5.5/3.5
Climbing ability (%)70% (35°)
The ground pressure (Kpa) is 41.7
Bucket digging force (kN) : 92.7
The digging force of the bucket arm (kN) is 66.13
Power system
Engine model: Isuzu 4JJ1-XDJAG-01-C3
Rated power (kw/rpm)73/2000
Maximum torque (N.m)365/1600
Displacement (L)2.999
The cooling method is water cooling
Oil capacity
Fuel tank (L)240
Hydraulic oil tank (L)150
Engine oil change volume (L)15
Main body size
The total length of transportation (mm) is 7,700
The total transportation width (mm) is 2550
Total transportation height (mm) : 2815
The total height of the cab (mm) is 2740
The width of the vehicle (mm) is 2490
Track grounding length (mm) : 2930
The total length of the track (mm) is 3665
Track plate width (mm) : 500
Track gauge (mm)1990
Minimum ground clearance (mm) : 425
The minimum turning radius (mm) of the front working device is 2500
The rear end turning radius (mm) is 2240
The maximum height (mm) at the minimum turning radius is 6500
Number of idler wheels (single side) (units)1
Number of track plates (single side) (pieces)44
Number of supporting wheels (single side) (units)7
Scope of work
Maximum excavation radius (mm) : 8290
Maximum excavation depth (mm) : 5510
Maximum excavation height (mm) : 8685
Maximum unloading height (mm) : 6180
The maximum vertical excavation depth (mm) is 4890
